| Dimensions | 130.0 x 42.0mm; thickness: 10.5mm |
| Weight | About 45g |
| Material | PC |
| Colour | Black (Red, Blue, Green, White) |
| Mounting Methods | Screw, adhesive, Cable tie |
| SDK | support |
| IP Rating | IP68 |
| Operating Temp. | -30°С to +80°С |
| Storage Temp. | -40°С to +100°С |
| Humidity | 5% RH – 95% RH non condensing |
| Frequency | US(902-928MHZ), EU(865-868MHZ) |
| Protocol | ISO18000-6C（EPC global UHF Class 1 Gen 2 ) |
| IC type | Alien Higgs-3 |
| Memory | EPC 96bits (Up to 480bits), USER 512bits, TID 64bits |
| Write Cycles | 100,000 times |
| Functionality | Read/write |
| Data Retention | 50 Years |
| Applicable Surface | Metal Surfaces |
| Read range(Fix Reader): | 30M – (US) 902-928MHz, 28M – (EU) 865-868MHz, On Metal 16M – (US) 902-928MHz, 14M – (EU) 865-868MHz, Off Metal |
| Read range(Handheld Reader): | 22M – (US) 902-928MHz, 22M – (EU) 865-868MHz, On Metal 11M – (US) 902-928MHz, 11M – (EU) 865-868MHz, Off Metal |
