PDA Mobile Computer with Built-in Printer

Category Printers

Features:

ZR-2 is an android PDA with 2inch built-in printer, support self-adhesive and thermal printing, which is very convenient to use in portable application scenarios, support barcode scanning, NFC at the same time, applicable for law enforcement, vehicle parking and retail industries.

6inch HD full screen 18:9, large visual size
Android 11 OS, high performance CPU
Supports barcode scanner, RFID, thermal printer at the same device
PC+TPU plastics, Two-color injection molding, rugged design, comfortable to grip

Parameter:

Physical Characteristics

Dimensions	1748235mm (the thickest part is 56mm)
Weight	about 460g (including battery) (N.W.; depends on configuration)
CPU	Octa-core, 2.0Ghz
RAM+ROM	4G+64GB or 6G+128GB
Display	6 inch Multi-touch panel, IPS 2160*1080, tempered glass
Colour	Black
Battery	Richargeable, removable 4000mAh
Camera	Rear camera 13MP AF High brightness LED flash, Front Camera 5MP FF
Interfaces	USB-Type C, support fast charge, support OTG Base Charging and USB Contacts; Support Base Extension
Card slot	Micro sim card slot; TF card: max 128GB
Audio	Microphone, noise reduction, speaker, receiver
Keypad	5 keys (power key, 2 * function keys, volume + -)
Sensors	3D accelerator,E-compass,proximtity sensor,Light sensor

Communication

WWAN	FDD-LTE B1/B4/B5/B7/B8 TDD-LTE B38/B39/B40/B41 WCDMA B1/B2/B5/B8 GSM B2/B5/B8 CDMA/EVDO BC0 BC1
WLAN	Support 802.11 a/b/g/n/ac, 2.4G/5G dual-band
Bluetooth	Bluetooth 4.1
GNSS	GPS, GLONASS, BeiDou

Developing Environment

Operating System	Android 11 or 8.1
SDK	Emagic Software Development Kit
Language	Java

Barcoding

1D & 2D Barcode Scanner	Honeywell: 6603/ Newland CM60
1D Symbologies	UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc.
2D Symbologies	PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX),etc.

User Environment

Operating Temp.	-10℃ +50 ℃
Storage Temp.	-20 ℃~+70 ℃
Humidity	5% RH – 95% RH non condensing
Drop Specification	Multiple 1.5 m / 4.92 ft. drops (at least 20 times) to the concrete across the operating temperature range;
Tumble Specification	1000 x 0.5 m / 1.64 ft. falls at room temperature
Sealing	IP65
ESD	±12 KV air discharge, ±6 KV conductive discharge

RFID

NFC	13.56 MHz; ISO14443A/B, ISO15693

Other Functions

Built-in Printer	2 inch adhesive printer Support adhesive and thermal printing; The print head has a lifetime of 50KM Roll diameter 40mm, speed 80mm/s
PSAM	Optional
