| Dimensions | 120x30mm, Front hole: D4mmx2; Side hole:10x2mmx2; thickness: 10mm |
| Weight | About 46g |
| Material | PC |
| Colour | Black or other color customizable |
| Mounting Methods | Screw, adhesive, Cable tie |
| RFID | RFID |
| SDK | support |
| IP Rating | IP68 |
| Operating Temp. | -25°С to +105°С |
| Storage Temp. | -40°С to +105°С |
| Humidity | 5% RH – 95% RH non condensing |
| Frequency | US(902-928MHZ), EU(865-868MHZ) |
| Protocol | ISO18000-6C（EPC global UHF Class 1 Gen 2 ) |
| IC type | Alien Higgs-3 |
| Memory | EPC 96bits (Up to 480bits), USER 512bits, TID64bits |
| Write Cycles | 100,000 times |
| Functionality | Read/write |
| Data Retention | 50 Years |
| Applicable Surface | Metal Surfaces |
| Read range(Fix Reader): | 9.5m, US(902-928MHZ); 9.3m, EU(865-868MHZ) |
| Read range(Handheld Reader): | 6.0m, US(902-928MHZ); 5.8m, EU(865-868MHZ) |
