Physical Characteristics
Technical information and configuration details.
| Dimensions | 168mm*113mm*68mm |
| Weight | about 500g(Without Paper Roll) |
| Battery | Richargeable, 7.4V, 2600mAh; support 80meters Printing |
| Interfaces | USB |
| Flash | Maximum 128MB |
CC4 Mobile Label Printer 110mm
CC4 is a very good mobile wireless thermal printer, support blue tooth or Wifi connection, support both thermal paper and label with sticker printing; widely used in logistics, warehouse, retail and other printing application scenarios. support Bluetooth＋WiFi connection Width can be adjusted...
Parameter
Detailed product specifications
Review product parameters, technical tables, communication options, development environment, and supported industrial functions.
Communication
Technical information and configuration details.
| Bluetooth | 2.1/4.0(BLE) |
| USB | support |
Developing Environment
Technical information and configuration details.
| Command Set | ESC/POS, CPCL |
| Driver | Windows PC/Windows CE/Mobile/Android |
| Software | EasyPrint |
Barcoding
Technical information and configuration details.
Not applicable
User Environment
Technical information and configuration details.
| Operating Temp. | -10℃ +50 ℃ |
| Storage Temp. | -20 ℃~+70 ℃ |
| Humidity | 5% RH – 95% RH non condensing |
RFID
Technical information and configuration details.
Not applicable
Other Functions
Technical information and configuration details.
| Print Method | Direct Thermal |
| Resolution | 203dpi |
| Paper Width | 46mm-110mm |
| Print Width | 104mm (Max) |
| Print Speed | 70mm/s (Max) |
| Media | Receipt/Label |
| Media Size | (46mm-110mm)/ Φ56mm(Max) |
| OLCD Indicator | Yes |
| Button/Indicator | Parameter Setting |
| Media Detecting | Black Mark(Double)/Label Gapl/Paper-out |
| Alarm | Battery-Low/Case-Open/Paper-out |
| Restoration | Yes |
| Case-Opening | One-Button-Pushing |
| Power Saving | Yes |
| Over-Heat Protection | Yes |
| Type | Thermal Paper/Label |
| Width | 46mm-110mm |
| Diameter | 56mm (Max) |
| Thickness | 50μm-180μm |
Accessories
Compatible accessories and options
Select optional accessories to build a complete deployment kit for charging, protection, mounting, data collection, and field operation.
Deployment support
Our engineering team can recommend accessories based on your scanning workload, application environment, and lifecycle requirements.
Accessory 01
Contact us for compatibility and availability.
Download
CC4_mobile-label-printer-EN-Emagic
164 KB
