RFID Readers Handheld RFID Readers

Handheld UHF RFID Reader Android 12.0 long range V720

V720 is a portable handheld PDA mobile computer, with RFID reader and barcode scanner, android 12 operating system, with a pistol grip, and large battery capacity of 10000mAh. UHF RFID is from RAIN RFID IMPINJ E710 chip, long reading range. These top standard configuration makes V720 be a outstanding performance UHF RFID reader PDA.

Why choose V720 Mobile RFID reader?

  • Wireless transmission, 4G, WIFI and bluetooth RFID reader
  • Large battery capacity support long working time
  • Large size screen, convenient for operation by hands.
  • Easy handheld operation, allowing users to move around freely while scanning tags
  • E710 high sensitivity, reading distance can be maximum 20m (white card)
  • Combine with optional functions: barcode, NFC RFID, fingerprint
Get a Quote View Parameters
01
03
04
09
10
01
03
04
09
10
Download: V720-Emagic-Datasheet

Parameter

Detailed product specifications

Review product parameters, technical tables, communication options, development environment, and supported industrial functions.

Physical Characteristics

Technical information and configuration details.

Dimensions 178*83*17mm
Weight about 580g (including battery) (N.W.; depends on configuration)
CPU MTK 6763- Octa-core
RAM+ROM 3GB+32GB (4GB+64GB optional)
Display 1280*720/ 5.2” IPS LTPS 1440 x 720 (Select 5.72 inch full screen), Multi-touch panel, Corning grade 3 glass toughened screen
Colour Black
Battery Removable polymer lithium ion battery; 3.7V/10000mAh
Camera Rear: 013MP Autofocus with flash; front: 5.0MP(optional）
Interfaces TYPE-C, support USB2.0; 3.5mm headset; OTG
Card slot micro sim card slots; TF card: max 128GB
Audio Microphone, noise reduction, speaker, receiver
Sensors 3D accelerator,E-compass,proximtity sensor,Light sensor

Communication

Technical information and configuration details.

WWAN (Asia, Europe, America) CMCC 4M：LTE B1,B3,B5,B7,B8,B20,B38,B39,B40,B41
WCDMA 1/2/5/8
GSM 2/3/5/8
WLAN WIFI 802.11 b/g/n/a/ac  frequency 2.4G+5G dual band WIFI,
Bluetooth BT5.0(BLE)
GNSS GPS

Developing Environment

Technical information and configuration details.

Operating System Android 12, GMS
SDK Emagic Software Development Kit
Language Java

Barcoding

Technical information and configuration details.

1D & 2D Barcode Scanner Honeywell 6603&Zebra se4710& Newland CM60
1D Symbologies UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5,
Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc.
2D Symbologies PDF417,  MicroPDF417,  Composite,  RSS, TLC-39,  Datamatrix,  QR  code,
Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet,  US Planet,
UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX),etc.

User Environment

Technical information and configuration details.

Operating Temp. -10℃ +50 ℃
Storage Temp. -20 ℃~+70 ℃
Humidity 5% RH – 95% RH non condensing
Drop Specification Multiple 1.5 m / 4.92 ft. drops (at least 20 times) to the concrete across the
operating temperature range;
Tumble Specification 1000 x 0.5 m / 1.64 ft. falls at room temperature
Sealing IP65
ESD ±12 KV air discharge, ±6 KV conductive discharge

RFID

Technical information and configuration details.

NFC (optional) Support ISO/IEC 14443A protocol, card reading distance: 3-5cm (optional)
LF 125/134.2KHz FDX-B and HDX according to ISO/IEC11784/5
UHF Frequency: 865-868 MHz / 920-925 MHz / 902-928 MHz
Protocol: EPC C1 GEN2 / ISO18000-6C
Antenna: spiral antenna (4dbi) built in
Power: 5 dBm to +30 dBm adjustable
Max Read Range: 0~20m
Reading speed: Up to 700 tags/sec reading 96-bit EPC

Other Functions

Technical information and configuration details.

Fingerprint(optional) Optional, support, capacitive USB press module
Image size：256*360pi xei；FBI PIV FAP10 certification；
Image resolution：508dpi
Acquisition speed: single frame image acquisition time ≤0.25s

Accessories

Technical information and configuration details.

Standard USB cable*1+ adapter*1
Optional /

Download

V720-Emagic-Datasheet

239 KB

Download File
